The Pioneer PLX1000 DJ turntable is a modern spin of a classic, precision engineered for the professional DJ/vinyl enthusiast. The high-torque direct drive turntable is equipped with a classic layout and a rubber-lined, S-shaped tone arm that improves isolation and prevents feedback. It is solidly built for excellent vibration damping and ultra-precise, high grade audio playback.
HIGH-TORQUE
The high-torque direct drive ensures stable rotation and exceptional control – and it reaches 33⅓ rpm in just 0.3 seconds thanks to a starting torque of 4.5kg/cm (or more).
EXCELLENT SOUND DESIGN
PLX-1000’s heavy-mass, die-cast zinc chassis prevents resonance and vibrations. The lower part of the unit is reinforced with 8mm-thick resin, plus 9mm-thick, vibration-damping material at the base. Plus the rubber-insulated tone arm reduces howling effects, while rubber and springs on the dampening parts of the insulator absorb external vibrations.
TEMPO CONTROL
Multi-tempo control lets you instantly pick up or slow down the track to ±8%, ±16% and ±50%, while a simple reset button instantly reverts to ±0%.
FLEXIBLE CONNECTIVITY
Interchangeable power and audio cables can be easily connected and replaced, and pro-grade gold-plated RCA jacks ensure low impedance and an amazing sound quality.
WHAT'S IN THE BOX
- PLX-1000
- Power cord
- Audio cable
- Ground wire
- Adapter for 45" record
- Turntable sheet
- Slip mat and sheet
- Dust cover
- Head shell
- Balance, sub and shell weights
- Operating instructions
Power consumption 9 W
Main unit weight 13.1 kg
Maximum dimensions
(W x H x D) 453 x 159 x 353 mm
Output RCA × 1
Turntable
Drive method :Quartz lock servo type direct drive
Motor: 3-phase brushless DC motor
Braking system : Electronic brake
Rotation speed : 33 1/3 rpm, 45 rpm
Rotation speed adjustment range :
±8%, ±16%, ±50%
Wow and flutter :0.1% or less WRMS (JIS WTD)
S/N ratio: 70 dB (DIN-B)
Turntable: Aluminium die-casting diameter: 332 mm
Starting torque: 4.5 kg/cm or more
Start time: 0.3 seconds (at 331/3 rpm)
* Cartridge not included
Tone arm
Arm type: Universal type S-shape tone arm, gimbal-supported type bearing structure, static balance type
Effective length: 230 mm
Overhang: 15 mm
Tracking error: Within 3°
Arm height adjustment range: 6 mm
Stylus pressure variable range: 0 g to 4.0 g (1 scale 0.1 g)
Proper cartridge weight: 3.5 g to 13 g (single cartridge)
- When shell weight is used: 3.5 g to 6.5 g
- When only balance weight is used: 6.0 g to 10 g
- When sub weight is used: 9.5 g to 13 g
Included accessories Turntable, turntable sheet, slip mat, slip sheet, dust cover,
head shell, balance weight, sub weight, head shell, shell
weight, adapter for EP record, power cord, audio cable,
ground wire, operating instructions
- High-torque direct drive ensures stable rotation and exceptional control
- Excellent sound design
- Multi tempo control with reset button
- Flexible connectivity
