ADAM AUDIO
Adam Audio A4V Studio Monitor
Designed for small studio spaces, short listening distances and immersive multi-speaker configurations, the Adam Audio A4V delivers accurate, full-bodied sound in a compact form factor.
The Adam A4V is a two-way speaker incorporating a 4-inch long-throw woofer made from the same Multi-Layer Mineral (MLM) fibers as other A Series speakers plus the classic X-ART tweeter. Onboard DSP-based tuning capabilities let you easily dial in the perfect sound for your space.
With a frequency range of 52 Hz to 45 kHz, the A4V can accommodate a broad spectrum of audio applications—from producing podcasts to mixing string quartets—and will fit well within immersive and 3D setups.
A Control Remote Software
The DSP-based functionality of all A Series monitors can be controlled remotely and in real time over ethernet using A Control.
Rotatable HPS Waveguide & X-ART Tweeter
Made from a new glass fiber polymer compound, the HPS waveguide enables the X-ART tweeter to disperse sound in space with controlled consistency.
Automated Room Correction with Sonarworks
ADAM Audio is proud to partner with Sonarworks on an automated room correction solution that runs directly on the DSP of A Series monitors.
Bass Reflex System, Cabinets and Mounting
The new A Series cabinets build on the heritage of ADAM Audio and the AX Series in particular.
5 Year Warranty
Adam Audio now offer a 5 year warranty as standard across the entire current range, allowing you to work without worrying about your gear. You can activate this by registering in the MyADAM section of their website.
Tweeter: | Rotatable X-ART Tweeter + HPS Waveguide |
Woofer: | 1x 4" MLM woofer with 25 mm / 1” voice coil |
Frequency response @ -6dB: | 53 Hz - 42 kHz |
Maximum SPL per speaker at 1 m: | 100 dB |
AD convertor: | 24-bit |
Internal sample rate: | 96 kHz |
Amplifier power RMS: | 110 W (woofer) + 20 W (tweeter) |
Crossover frequency: | 3.0 kHz |
Power rating: | 300 W max |
Analog Input (balanced): | 1x XLR |
Analog Input (unbalanced): | 1x RCA |
Net Weight: | 5.8 kg (12 lbs 13 oz) |
Gross Weight: | 7.3 kg (16 lbs 1 oz) |
Cabinet Height x Width x Depth: | 268 x 158 x 220 mm (10 1/2" x 6 1/4" x 8 5/8“) |
Box Dimensions: | 390 x 285 x 345 mm (15 3/8" x 11 1/4" x 13 5/8") |
AC Input Voltage: | 100 – 240 V, 50/60 Hz |
- German Handmade Precision X-ART Tweeter with rotatable HPS waveguide
- 4'' Woofer (Multi-Layer Mineral)
- Cumulated Amp. Power Peak: 130 W
- Frequency Response @ -6 dB: 52 Hz - 45 kHz
- Maximum SPL per speaker at 1 m: 100 dB SPL
