ADAM AUDIO
Adam Audio A8H-R Side Near/Midfield 3-Way Studio Monitor
The Adam Audio A8H incorporates an 8-inch resonant Multi-Layer Mineral (MLM) fiber woofer, innovative midrange driver, and handmade precision X-ART tweeter, which together produce an ultra-wide frequency response.
Like the other members of the A Series family, the A8H gives you tremendous flexibility for fine-tuning the sound through rotatable HPS waveguide technology and onboard DSP. At home across a full range of audio applications in mid- to full-sized spaces, the A8H is the right choice when you’re looking for the most detailed representation of your audio.
The left and right version, A8H-L and A8H-R are sold separately.
A Control Remote Software
The DSP-based functionality of all A Series monitors can be controlled remotely and in real time over ethernet using A Control.
Rotatable HPS Waveguide & X-ART Tweeter
Made from a new glass fiber polymer compound, the HPS waveguide enables the X-ART tweeter to disperse sound in space with controlled consistency.
Bass Reflex System, Cabinets and Mounting
The new A Series cabinets build on the heritage of ADAM Audio and the AX Series in particular.
Automated Room Correction with Sonarworks
ADAM Audio is proud to partner with Sonarworks on an automated room correction solution that runs directly on the DSP of A Series monitors.
5 Year Warranty
Adam Audio now offer a 5 year warranty as standard across the entire current range, allowing you to work without worrying about your gear. You can activate this by registering in the MyADAM section of their website.
- Tweeter: Rotatable X- ART Tweeter + HPS Waveguide
- Midrange Driver: 3.5” MLM midrange driver
- Midrange Voice Coil Ø: 33 mm / 1.3”
- Woofer: 1x 8" MLM mid-woofer
- Woofer Voice Coil Ø: 38 mm / 1.5”
- AD convertor: 24-bit
- Internal sample rate: 96 kHz
- Amplifier power RMS: 250 W (Woofer) + 70 W (Midrange Driver) 20 W (Tweeter)
- Crossover frequency: 400Hz – 3.0 kHz
- Power rating: 500 W max
- Analog Inputs (balanced): 1x XLR
- Analog Inputs (unbalanced): 1x RCA
- Net Weight: 13.6 kg / 30 lbs
- Gross Weight: 16.6 kg / 36 lbs 10 oz
- Cabinet Height x Width x Depth: 274 mm x 382 mm x 329 mm [9 3/4" x 15" x 13"]
- Box Dimensions: 405 mm x 510 mm x 455 mm [16“ x 20 1/8“ x 17 7/8“ ]
- AC Input Voltage: 100 - 240V, 50/60 Hz
- Single Unit Weight: 13.6 kg
- Boxed Weight: 16.6 kg
- German Handmade Precision X-ART Tweeter with rotatable HPS waveguide
- 8'' Woofer (Multi-Layer Mineral)
- 3.5" DCH Midrange Driver
- Cumulated Amp. Power Peak: 340 W
