ART Cleanbox Pro 2-Way Stereo Converter
The ART Clean Box Pro converts two channels of unbalanced signal to a balanced level and and two channels of balanced signal to a unbalanced level. The CleanBox Pro is rugged, compact, and portable for studio and stage use. The CleanBox Pro from ART has two RCA jack inputs and a stereo mini-phone jack input connected in parallel. The Clean box pro reduces noise and is the cleanest way of connecting audio equipment, especially when long lengths of cable are used. Each section has stereo level controls to optimize signal levels. An LED indicator lights when power is applied. - The Clean Box Pro can be used with: mixers, audio processors, laptop computers, computer sound cards, CD/DVD players, video gaming machines, MP3 player/recorders, powered monitors and digital audio workstations.
ART CleanBox Pro Dual Channel Level Converter Specifications
Frequency Response: 20 Hz - 20 kHz, ± 1 dB
Total Harmonic Distortion: Signal to Noise Ratio: > 90 dB
Common Mode Rejection Ratio: > 40 dB
Input Impedance:
Balanced - 20k Ohms
Unbalanced - 100k Ohms
Output Impedance:
Balanced: 100 Ohms
Unbalanced: 300 Ohms
Maximum Gain:
Balanced to Unbalanced: -6 dB
Unbalanced to Balanced: +21 dB
Maximum Input Level: +21 dBu
Maximum Output Level:
Balanced: +21 dBu
Unbalanced: +15 dBu
Power: 7.5-12 V AC/DC, Dimensions (DxWxH):
1.85 x 4.6 x 4.3 (in)
47 x 117 x 109 (mm)
Weight: 1.10 lbs / 0.50 kg
- XLR connectors for balanced inputs and outputs
- RCA phono jacks and stereo 1/8" mini-phone jacks for unbalanced inputs and outputs
- Stereo unbalanced output level control
- Stereo balanced output level control
- Rugged extruded aluminum case
- Lighted On/Off switch
