Arturia Audiofuse REV2 Compact Audio Interface
Arturia Audiofuse Rev 2
The Arturia AudioFuse Rev 2 is a premium audio interface designed to deliver professional studio-grade sound in any environment. Whether you're working from a desktop, hotel room, or live venue, the AudioFuse maintains the purity and detail of your sound through high-end DiscretePRO® microphone preamps and top-tier AD/DA converters. It's built to faithfully capture everything from delicate ambience to powerful performances, transforming any space into a world-class recording setup with uncompromising quality.
More than just sound, the AudioFuse emphasizes seamless workflow and creative efficiency. It offers advanced features like detailed metering, talkback communication, A/B monitor switching, direct monitoring, and professional insert points—all in a compact, rugged aluminium chassis. With ultra-low latency, broad compatibility (Mac, PC, iOS, Android), and robust connectivity for everything from mics to turntables, it’s a versatile, high-performance solution for artists, producers, and engineers who demand reliability, clarity, and control in their creative process.
Phono preamps for connecting turntables
The AudioFuse Rev 2 features two dedicated RIAA phono preamps with grounding terminals, making it perfect for connecting turntables directly without the need for external amplifiers. This allows DJs, vinyl enthusiasts, and sampling artists to enjoy pristine, high-fidelity playback and accurate vinyl digitization straight into their DAW, all with minimal setup and maximum sound integrity.
Main features of the Audiofuse Rev 2 include:
- 2 DiscretePRO microphone preamps
- 2 RIAA phono preamps
- 4 analog inputs
- 2x Mic/Instrument/Line (XLR / 1/4" TRS)
- 2x Phono/Line (RCA / 1/4" TRS)
- 4 analog outputs (1/4" TRS)
- 2 analog inserts (1/4" TRS)
- ADAT in/out
- S/PDIF in/out
- Word clock in/out
- 24-bit next-generation A-D/D-A converters at up to 192kHz sampling rate
- MIDI in/out
- Talkback with dedicated built-in microphone (up to 96 kHz Sample Rate)
- A/B speaker switching
- Direct monitoring
- 2 independent headphone outputs
- Separate master and monitor mix channels
- USB interface with PC, Mac, iOS, Android compatibility
- 3-port USB hub
- Aluminum chassis, hard leather-covered top cover
- DiscretePRO® Technology
Line Inputs
- Input impedance: 20kΩ (symmetric), 10kΩ (asymmetric)
- Maximum input level: +24dBu
- Gain range: from -15dB to 36dB
- Pad mode: -20dB
- Frequency response (20Hz to 20kHz): ±0.08 dB
- Dynamic range: 117dB (A-weighted)
- THD+N: -106dB (A-weighted)
Instrument Input
- Input impedance: 1.1MΩ asymmetric
- Maximum input level: +18dBu
- Gain range: from -15dB to 36dB
- Pad mode: -20dB
- Frequency response (20Hz to 20kHz): ±0.08 dB
- Dynamic range: 117dB (A-weighted)
- THD+N: -104dB (A-weighted)
Line Aux
- Input impedance: 20kΩ (symmetric), 10kΩ (asymmetric)
- Maximum input level: +24dBu
- Pad mode: -20dB
- Frequency response (20Hz to 20kHz): ±0.08 dB
- Dynamic range: 118dB (A-weighted)
- THD+N: -104dB (A-weighted)
Microphone Preamps
- Input impedance: 3.4kΩ
- Maximum input level: +11dBu
- Gain range: from 3dB to 76dB
- Boost mode: +10dB
- Pad mode: -20dB
- Frequency response (20Hz to 20kHz): ±0.08 dB
- Equivalent Input Noise (EIN): -131.5dBu typical (A-weighted)
- THD+N: -104dB (A-weighted)
Inserts
- Output impedance: 33Ω
- Input impedance: 10kΩ
- Dynamic range: 119dB (A-weighted)
- Maximum output level: +18dBu
- Maximum input level: +18dBu
- THD+N: -104dB (A-weighted)
Speakers
- Output impedance: 120Ω
- Maximum output level: +24dBu
- Dynamic range: 119dB (A-weighted)
- THD+N: -104dB (A-weighted)
Phones
- Output impedance: 33Ω
- Maximum output level: +10dBu
- Dynamic range: 102dB (A-weighted)
- THD+N: -87dB (A-weighted)
