IKMULTIMEDIA
iRig Pre Universal Microphone Interface for iPhone/iPod Touch/iPad
"The iRig Pre is the first studio quality microphone preamp for the iOS platform; compatible with iPhone/iPod Touch/iPad.Here's how you use it: Take the microphone you use every day on stage or in the studio and plug it into your iOS device. It's that simple. Need Phantom Power? Flip the Phantom Power switch. Congratulations, you've just become a professional user."
iRig PRE Specifications
Frequency response: from 20 Hz to 20 kHz +/- 1.5dB
Noise: -98 dB fullband, phantom power ON
Maximum output level: 2 Vrms
Distortion: 0.025% THD
Phantom max current: 6mA
Battery duration (Alkaline 9V cell): approx 30 hours when phantom is off, approx 10 hours when phantom is on
Package includes
Dimensions
iRig PRE
9V Battery
Velcro Strip
32mm/1.26" x 35mm/1.38" x 83mm/3.27"
(W x L x H)
Cable lenght: 450mm/17.72"
(Connector included)
Weight: 100g/3.53oz (Battery included)
Requirements
iOS Devices
iRig PRE is compatible with iPhone 5, iPhone 4S, iPhone 4, iPhone 3GS, iPod touch (5th, 4th and 3rd generation), iPad 4th generation, iPad 3rd generation, iPad 2, iPad and iPad mini. iOS 4.3 or later is required.
Android Devices
Works with most Android devices including: Google Nexus S, HTC Desire HD, Samsung Galaxy S III, Samsung Galaxy S II, Samsung Galaxy W, Samsung Galaxy S, Samsung Galaxy Note, Samsung Galaxy Nexus, Samsung Galaxy Tab 10.1, Samsung Galaxy Tab 7 plus.
Computers
Mac®: Most Mac computers starting from late 2008 are compatible with the exception of the Mac Pro line.
To check if your Mac is compatible select: About This Mac > More Info > System Report > Audio
and check that "External Microphone / iPhone headset" is appearing on the list of included features.
Dimensions
Requirements
iOS Devices
iRig PRE is compatible with iPhone 5, iPhone 4S, iPhone 4, iPhone 3GS, iPod touch (5th, 4th and 3rd generation), iPad 4th generation, iPad 3rd generation, iPad 2, iPad and iPad mini. iOS 4.3 or later is required.
Android Devices
Works with most Android devices including: Google Nexus S, HTC Desire HD, Samsung Galaxy S III, Samsung Galaxy S II, Samsung Galaxy W, Samsung Galaxy S, Samsung Galaxy Note, Samsung Galaxy Nexus, Samsung Galaxy Tab 10.1, Samsung Galaxy Tab 7 plus.
Computers
Mac®: Most Mac computers starting from late 2008 are compatible with the exception of the Mac Pro line.
To check if your Mac is compatible select: About This Mac > More Info > System Report > Audio
and check that "External Microphone / iPhone headset" is appearing on the list of included features.
Features:
40 cm (15.75") TRRS cable to connect
to any iOS device headset jack
XLR input connector for microphones
Gain control
+48 V phantom power
Headphone output
On/Off switch
Power/Phantom Power provided by 9V battery
Battery life is approximately
30 hours with dynamic microphones
and 10 hours with phantom powered condenser studio microphones
Download 2 free apps from the App Store:
iRig Recorder FREE, an easy-to-use voice recording/editing app,
VocaLive FREE, a multi-effects processing app for singers.
Compatible with iPhone/iPod touch/iPad.
