Korg handytraxx play
Korg handytraxx play
The Korg handytraxx play reimagines the classic portable turntable with modern innovation. Designed for DJs, vinyl enthusiasts, and creative performers, it combines portability with cutting-edge features, including unique Korg digital effects, a built-in audio looper, and a high-quality fader optimised for scratching.
Developed in collaboration with Toshihide Nakama, co-creator of the original Handy Trax, this redefined turntable blends tradition and technology, delivering a truly unparalleled experience for music lovers on the go. Whether you’re spinning at home or showcasing your skills anywhere, the handytraxx play is your perfect companion.
- Main features of the Korg handytraxx play include
- Developed in collaboration with Toshihide Nakama, co-creator of the original Handy Trax.
- Incorporates Korg’s digital processing technologies while staying true to the original design.
- Dedicated to honouring Toshihide Nakama’s legacy, who passed during development.
- Optimised for exceptional scratching with a high-quality fader offering smooth, precise motion.
- Minimised silent zones and reverse scratch functionality enhance performance.
- Features three digital filter types: DJ filter, EQ filter with low isolator, and peaking wah filter with modulation.
- Built-in delay effect for creating ambient soundscapes or bold echoes.
- Integrated audio looper for live playback capture, scratching over loops, and seamless record swapping.
- Variable speed control switch for adjusting playback speed (33/45 RPM) and layering recordings.
- Custom-designed tonearm minimises needle skipping during playback and scratching.
- Belt-driven motor with digital rotation correction ensures stable platter rotation and quick recovery.
- Powered by AC adapter or six AA batteries for ultimate portability.
- Built-in 2.5W speaker delivers rich bass and clear playback without needing external speakers.
- Flexible customisation with support for ceramic and MM cartridges.
- Scratch fader and control panel can be reoriented for right- or left-handed use.
- Drive system: Belt-driven (with digital rotation correction)
- Drive motor: DC servo motor
- RPM: 33-1/3, 45, or 78 revolutions per minute
- S/N (signal-to-noise) ratio: Less than 60 dB (DIN-B)
- Cartridge model: Stereo ceramic cartridge included (MM supported)
- Maximum input level: AUX IN: 2.5 Vp
- Maximum output level:
- LINE OUT: 2.3 Vp, THD 1%
- PHONO OUT: 300 mV (1 kHz, 5cm/sec)
- PHONO preamp gain:
- Standard value: 34.5 dB
- Equalizer characteristics: RIAA
- Digital signal processing:
- A/D, D/A: 44.1 kHz@16-bit, stereo
- Crossfader: 44.1 kHz, 32-bit float, stereo
- Mix: 44.1 kHz, 32-bit float, stereo
- Looper: 44.1 kHz, 16-bit, stereo; max. recording time: approx. 20 sec
- Filter: 44.1 kHz, 32-bit float, stereo; types: OFF, FILTER1, FILTER2, FILTER3
- Delay: 44.1 kHz, 32-bit float, stereo; feedback (0%–80%), time (1,000 ms–10 ms)
- Power consumption: 2.35 W
- Power supply: AC adapter (included), six AA batteries (alkaline or nickel-metal hydride)
- Weight: 2.3 kg / 5.07 lb
- Dimensions:
- 370 x 280 x 84 mm / 14.57˝ x 11.02˝ x 3.30˝
- With cover on: 370 x 286 x 87 mm / 14.57˝ x 11.26˝ x 3.43˝
- Included items:
- AC adapter
- AC adapter replacement plug (5 types)
- Dust cover
- Slip mat
- EP adapter
- Quick Start Guide
