QTX
QTX Pixelator: 144pcs Pixel LED Effects Bar (151616
LED effects bar fitted with 144 RGB SMD's to provide a wide range of bright and colourful patterns and effects. Various automatic shows and settings can be run directly from the unit, or using sound to light. Alternatively the bar can be operated remotely by DMX in various channel modes and connected to multiple units if a larger effect is needed. Supplied with twist and lock power lead and tilt-adjustable brackets for hanging, truss mounting or free-standing.
- In the Box
- Pixelator main unit
- Twist and lock UK mains lead (2m)
- Mounting brackets and thumbscrews
- User guide
- Power supply: 110-240Vac, 50/60Hz
- Power consumption: 60W
- LED : type: 144Pcs SMD 5050 3IN1 RGB LEDs
- Beam angle 90°
- Modes: Auto, Show, Sound, Master/Slave, DMX
- DMX channels: 3, 5, 8, 36 or 40CH: Connections: Power in/out (twist and lock), DMX in/out (3pin XLR)
- Dimensions: 60 x 80 x 1010mm
- Weight: 1.54kg
- 144pcs of high output SMD5050 RGB LEDs produce a vast array of colourful moving effects and washes
- Automatic, show and sound modes that can be tailored to your requirements using additional speed, sensitivity and strobe settings
- Connect to multiple units and control using DMX for a wider effect
- 3, 5, 8, 36 or 40 channel DMX modes
- Twist and lock power connections for a more professional feel
- Supplied with dual mounting brackets for hanging, truss mounting or free-standing
